| 코드 No. |
토크조절범위 |
| 표준 |
Out
side dia'(mm) |
Chuck
grip
|
Length
mm
|
Weight
Kg
|
최소~최대
단위 : gf·cm(N·m)/Kgf·cm(N·m) |
1눈금 |
| 45ATG |
43.5 |
1~6.5Φ
|
90
|
0.18
|
5~45 (0.05~0.45)
gf·cm(N·m) |
1 (0.01) |
| 90ATG(S) |
10~45 (0.1~0.9)
gf·cm(N·m) |
2 (0.02) |
| 150ATG(S) |
20~150 (0.2~1.5)
gf·cm(N·m) |
2 (0.02) |
| 300ATG(S) |
30~300 (0.3~3)
gf·cm(N·m) |
5 (0.05) |
| 600ATG(S) |
60~600 (0.6~6)
gf·cm(N·m) |
10 (0.1) |
|
1200ATG(S) |
100~1200
(1~12) gf·cm(N·m) |
20 (0.2) |
| 2400ATG(S) |
30~2400 (3~24) gf·cm(N·m) |
50 (0.5) |
| 1.5BTG(S) |
64.2 |
1~8.5Φ
|
118
|
0.18
|
0.2~1.5
(2~15) Kgf·cm(N·m) |
0.02 (0.2) |
| 2.4BTG(S) |
0.3~2.4 (3~24)
Kgf·cm(N·m) |
0.05 (0.5) |
| 3.6BTG(S) |
0.4~3.6
(4~36)
Kgf·cm(N·m) |
0.05 (0.5) |
| 6BTG(S) |
0.6~6
(6~60) Kgf·cm(N·m) |
0.1 (1) |
| 9BTG(S) |
1~9
(10~90) Kgf·cm(N·m) |
0.1 (1) |
| 15BTG(S) |
2~15
(20~150) Kgf·cm(N·m) |
0.2 (2) |
|
정도±2%
|
물성측정/전자계측기물리량측정기
토크게이지
