ELECTRICAL SPECIFICATIONS :
■ DC Current [TES-3092]
|
Range |
Resolution |
Accuracy |
Overload protection |
|
200A |
0.1A |
±(1.5%rdg ± 2dgts) |
850Arms |
|
800A |
1A |
■ AC Current [TES-3091/3092]
|
Range |
Resolution |
Accuracy |
Frequency Range |
Overload protection |
|
200A |
0.1A |
±(2%rdg ± 4dgts) |
50 / 400Hz |
800Arms |
|
700A |
1A |
■
DC Voltage(Auto Range)
[TES-3092]
|
Range |
Resolution |
Accuracy |
Input
Impedance |
Overload
protection |
|
200V |
0.1V |
±(1%rdg ± 1dgts) |
1MΩ |
600Vrms |
■ AC Voltage [TES-3091/3092]
|
Range |
Resolution |
Accuracy |
Frequency
Range |
Input
Impedance |
Overload
protection |
|
600V |
1V |
±(1.5%rdg ± 4dgts) |
50 ~ 400Hz |
1MΩ |
600Vrms |
■
Ohms(Resistance)
[TES-3091/3092]
|
Range |
Resolution |
Accuracy |
Overload protection |
|
2KΩ |
1Ω |
±(1%rdg ± 2dgts) |
600Vrms |
■
Continuity Beeper
[TES-3091/3092]
|
Range |
Sound Level |
Max Open Circuit Voltage |
Overload protection |
|
|
≤30Ω |
3V |
600Vrms |
GENERAL SPECIFICATIONS :
- LCD Display : 3-1/2 digits, (MAX 1999), OL for over-range
indication
 for Low battery indication
- Power Source : One 9V battery(006P or IEC6F22)
- Battery Life : 3091:200hr, 3092:100hr
- Operating/Storage Condition : 0℃ to 50℃ < 80%RH, -10℃ to 60℃
< 70%RH.
- Dimensions : 192(L) x 64(W) x 31(H)mm
- Weight : Approx. 240g
- Jaw Opening Diameter : Cables 27 mm
- Accessories : Instruction Manual ,Battery, Test Leads and Carrying
Case
|
